Manufacturing

Wind Regions A-C, Terrain Categories 1-3

Type 1: 20m2 Sail Area 3,800kg load:

• 1-25: 25m tapered steel pole

• 1-30: 30m tapered steel pole

• 1-35: 35m tapered steel pole

Type 2: +5m 6m2 Sail Area, 500kg load +1m 20m2 Sail Area, 3,800kg load -5m 10m2 Sail Area, 2,600kg load:

• 2-25: 25m tapered steel pole

• 2-30: 30m tapered steel pole

• 2-35: 35m tapered steel pole

• Modular steel Triangular

• Modular steel Hexagon

• Modular steel Square

• Custom designs

 Pole designs are optimised for the particular application to ensure that best possible economical, environmental, structural and performance outcomes are achieved. Pole accessories are also considered as part of the ‘made-to-order’ process and designed in line with specific customer needs.

• AS/NZS 4600:2005 Cold formed steel structures

• AS/NZS 4100:1998 Steel structures

• ASCE/SEI 48-11 Design of Steel Transmission Pole Structures AS/ NZS 1170.0:2002 Structural design actions • AS/NZS 1170.2:2011 Wind loads

• Pole data, for modelling in PLS Pole, is available upon request

• Steel in accordance with certified international standards, comparable to equivalent Australian Standards

• Weld quality in accordance with AS/NZS 1554.1:2011. Tolerances in accordance with AS/NZS 4677:2010 Steel utility services poles

• Hot dip galvanising after all fabrication in accordance with AS/ NZS4680:2006
